Description
The Haier 18HJ Puri Inverter ODU is designed to deliver powerful and energy efficient cooling with advanced DC inverter technology. Built for stable performance, it ensures consistent airflow and reliable operation in demanding conditions. Its durable outdoor unit construction enhances longevity and reduces maintenance needs. Ideal for residential and commercial use, it provides efficient climate control with long lasting performance.
Key Features
✅ Cooling:Yes
✅ Heating:Yes
✅ Dry:Yes
✅ Vertical Flapper Auto Swing:Yes
✅ Horizontal Louvers Auto Swing:Yes
✅ Air Purification:Yes
✅ WiFi:Yes
✅ Self Clean:Yes
✅ Anti Corrosion:Yes
✅ Turbo Function:Yes
✅ UPS Enable:Yes
Technical Specifications
| Specification | Value |
|---|---|
| Performance Specifications | |
| Capacity wise | 1.5-Ton |
| Category wise | DC Inverter |
| Color | Golden |
| Cooling Capacity BTU | 21500 |
| Running Current Cooling (A) | 2.3 ~ 8.1 |
| Power input Cooling (KW) | 0.52 ~ 1.85 |
| Heating Capacity BTU | 20300 |
| Running Current Heating (A) | 2.4 ~ 8.3 |
| Power Input Heating (KW) | 0.42 ~ 1.91 |
| Other Parameters | |
| Input Power Supply (Ph, VAC, Hz) | 1PH, 230V ~, 50Hz |
| Air Flow Volume (m³/h) | 1150 |
| Refrigerant Type | R-32 |
| Refrigerant Amount (G) | 1200 |
| Indoor Unit Parameters | |
| Indoor Net Dimension (L×W×H) mm³ | 1045×230×335 |
| Indoor Packing Net Dimension (L×W×H) mm³ | 1160×347×455 |
| Indoor Net Weight (kg) | 15.5 |
| Indoor Gross Weight (kg) | 20 |
| Outdoor Unit Parameters | |
| Outdoor Net Dimension (L×W×H) mm³ | 815×310×630 |
| Outdoor Packing Net Dimension (L×W×H) mm³ | 942×392×693 |
| Outdoor Net Weight (kg) | 37.5 |
| Outdoor Gross Weight (kg) | 41.5 |
| Accessories | |
| Installation Kit (Liquid side) | Copper, 2920×6×0.65mm (6mm) |
| Installation Kit (Gas side) | Copper, 2920×12×0.65mm (12mm) |
| Power Cable | 3×2.5mm² |
| Communication Cable (Indoor & Outdoor) | 4×2.5mm² |
| Warranty | |
| Compressor | 10 Years |
| PCB Kit | 4 Years |
| Parts | 1 Year |
A+++ EU Standard Energy Saving
The A+++ EU Standard Energy Saving system delivers powerful, stable cooling with reduced power consumption. It offers five adjustable energy-saving levels, ensuring high efficiency and optimal performance.
Air Purification
The Purifier T3 Plus Inverter features advanced air purification technology, delivering a Clean Air Delivery Rate (CADR) of up to 300 cubic meters per hour, capable of purifying an entire room in just 15 minutes.
