Description
The 24T5 CFRESH TCL FreshIN Floor Standing AC is designed to deliver powerful and consistent cooling for large areas. Featuring FreshIN technology, it brings in fresh air while maintaining a comfortable indoor environment. Its strong airflow and energy efficient performance make it ideal for halls, offices, and commercial spaces. With a modern floor standing design and reliable build quality, it ensures long lasting comfort and performance.
Key Features
✅ 70 m³ per hour fresh air supply for a healthier indoor environment
✅ Visible air purification with QuadruPuri filters for cleaner and safer air
✅ Fast cooling for quick and effective temperature control
✅ Six speed Gen mode for flexible and customized airflow
✅ Smart app control with AI voice control for easy and convenient operation
✅ Stable operation at extreme high temperatures up to 60°C
✅ Gentle breeze mode with indoor and outdoor self clean function
Technical Specifications
| Specification | Details |
|---|---|
| General Information | |
| Type | Heating Pump, DC Inverter |
| Control Type | Remote |
| Compressor Type | Rotary |
| Refrigerant | R32 / 1.22 kg |
| Suitable Area (㎡) | 30 ~ 50 |
| Cooling Performance | |
| Rated Cooling Capacity (BTU/h) | 26000 |
| Rated Cooling Capacity (W) | 7600 |
| EER for Cooling (W/W) | 3.5 |
| Power Input - Cooling (W) | 220 ~ 3300 |
| Max Power Input - Cooling (W) | 3300 |
| Current - Cooling (A) | 1.0 - 15.0 |
| Max Current - Cooling (A) | 15 |
| Heating Performance | |
| Rated Heating Capacity (BTU/h) | 30000 |
| Rated Heating Capacity (W) | 8800 |
| COP for Heating (W) | 3.5 |
| Power Input - Heating (W) | 200 ~ 4095 |
| Max Power Input - Heating (W) | 4095 |
| Current - Heating (A) | 1.0 - 18.0 |
| Max Current - Heating (A) | 18 |
| Additional Performance | |
| Moisture Removal (Liters/h) | 2.4 |
| Indoor Air Volume (Cooling/Heating) (m³/h) | 1750 |
| Electrical | |
| Power Supply | 220V-240V~ 1 Phase / 50Hz |
| Voltage Range (V) | 155 ~ 264 |
| Indoor Fan Motor Type | DC Motor |
| Outdoor Fan Motor Type | DC Motor |
| Pressure | |
| Pressure - High (DP) (MPa) | 3.7 |
| Pressure - Low (SP) (MPa) | 1.2 |
| Noise Levels | |
| Indoor Noise Level - High (dB(A)) | 45 |
| Indoor Noise Level - Med. (dB(A)) | 42 |
| Indoor Noise Level - Low (dB(A)) | 38 |
| Outdoor Noise Level (dB(A)) | 56 |
| Operating Temperature | |
| Ambient Temperature (℃) | -20 ~ 60 |
| Dimensions - Indoor Unit | |
| Net Dimensions (W × D × H) mm | Φ378 × 1858 |
| Packing Dimensions (W × D × H) mm | 1985 × 497 × 550 |
| Net Weight (kg) | 40 |
| Gross Weight (kg) | 50 |
| Dimensions - Outdoor Unit | |
| Net Dimensions (W × D × H) mm | 920 × 380 × 699 |
| Packing Dimensions (W × D × H) mm | 977 × 439 × 750 |
| Net Weight (kg) | 48 |
| Gross Weight (kg) | 53 |
T-AI Energy-saving
T-AI enables the compressor to proactively adjust its operation frequency, allocating the majority of power towards cooling.This enables 37%+ additional energy savings on top of inverter performance.
OTA Updates
With OTA updates through TCL Home APP, and cloud-based data, the air conditioner's smart system is continuously optimized, ensuring a consistently great user experience.
